Product SKU | MFS3581C |
Brand | KTS Turbobillet X |
Availability | In Stock |
Quantity |
|
Description
Highlight
KTS Turbobillet X (KTS) is a specialty manufacturer of high performance Machined-From-Solid (MFS) Compressor wheel, also known as Billet Impeller.
Any Inquiry feel free to contact us via:
Facebook: www.facebook.com/KtsTurbobilletX
Email: sales2@ktsturbobilletx.com
KTS MFS P/N |
3581 |
OE MODEL |
GT3582 |
OE COMPRESSOR WHEEL P/N |
UNK |
OE TURBOCHARGER P/N |
UNK |
APPLIED TO ENGINE/VEHICLE |
UNK |
FITS COMPRESSOR HOUSING |
Custom |
NOSE DIAMETER (mm) |
13.53 |
INDUCER (mm) |
62.70 |
EXDUCER (mm) |
82.00 |
TIP EXDUCER (mm) |
90.21 |
TIP HEIGHT (mm) |
5.81 |
SUPERBACK (mm) |
2.35 |
BORE SIZE (mm) |
6.35 |
BORE TYPE |
Through |
OVERALL HEIGHT (mm) |
35.68 |
BLADE NUMBER |
7+7 |
ROTATION |
Forward |
What's in the box
KTS Billet Compressor Wheel MFS3581C x 1pc
